Täieliku komplekti rull-laagrid NNCL tüüpi
Topeltsilindrilised silindrilised laagrid, mis jagunevad järgmisteks tüüpideks:
NNF-tüüpi ADA2LSV / SL04 topeltjooneline täismassiga silindriline rull-laagrid
NNC tüüp / SL01 seeria täismassiga silindrilised rull-laagrid
NNCL-tüüpi / SL02-seeria silindrilised rull-laagrid
NCF ... V tüüpi / SL18 tüüpi täiskomplekti silindrilised rull-laagrid
NNCL tüübil on kolm fikseeritud äärikut, samas kui välimine rõngas on ääristeta. Võlli aksiaalne nihkumine korpuse suhtes mõlemas suunas saab mahutada laagrisse. Seda tüüpi laager on saadaval ujuvlaagritena, neil on lihtsalt radiaalne kandevõime.
Tüüp | Mõõdud | Nimikoormus | Kiiruse piiramine | Mass | Vastavalt DIN5412 | |||
(mm) | (KN) | (r / min) | (kg) | |||||
SL024830 | 150 | 190 | 40 | 231 | 530 | 1910 | 2.8 | NNCL4830V |
SL024832 | 160 | 200 | 40 | 237 | 560 | 1820 | 3 | NNCL4832V |
SL024834 | 170 | 215 | 45 | 260 | 600 | 1690 | 3,95 | NNCL4834V |
SL024836 | 180 | 225 | 45 | 270 | 640 | 1590 | 4.15 | NNCL4836V |
SL024838 | 190 | 240 | 50 | 310 | 730 | 1510 | 5.45 | NNCL4838V |
SL024840 | 200 | 250 | 50 | 320 | 770 | 1440 | 5.7 | NNCL4840V |
SL024844 | 220 | 270 | 50 | 335 | 840 | 1320 | 6.2 | NNCL4844V |
SL024848 | 240 | 300 | 60 | 510 | 1260 | 1210 | 9.9 | NNCL4848V |
SL024852 | 260 | 320 | 60 | 540 | 1370 | 1120 | 10.6 | NNCL4852V |
SL024856 | 280 | 350 | 69 | 700 | 1820 | 1020 | 15.6 | NNCL4856V |
SL024860 | 300 | 380 | 80 | 820 | 2070 | 960 | 22 | NNCL4860V |
SL024864 | 320 | 400 | 80 | 850 | 2220 | 900 | 23.5 | NNCL4864V |
SL024868 | 340 | 420 | 80 | 870 | 2330 | 860 | 25 | NNCL4868V |
SL024872 | 360 | 440 | 80 | 900 | 2480 | 810 | 26 | NNCL4872V |
SL024876 | 380 | 480 | 100 | 1320 | 3500 | 750 | 44 | NNCL4876V |
SL024880 | 400 | 500 | 100 | 1350 | 3650 | 720 | 45.8 | NNCL4880V |
SL024912 | 65 | 85 | 25 | 70 | 121 | 4500 | 0,47 | NNCL4912V |
SL024914 | 70 | 100 | 30 | 106 | 185 | 3800 | 0,75 | NNCL4914V |
SL024916 | 80 | 110 | 30 | 112 | 206 | 3450 | 0,85 | NNCL4916V |
SL024918 | 90 | 125 | 35 | 153 | 290 | 3000 | 1.3 | NNCL4918V |
SL024920 | 100 | 140 | 40 | 191 | 370 | 2700 | 1.9 | NNCL4920V |
SL024922 | 110 | 150 | 40 | 198 | 400 | 2500 | 2.1 | NNCL4922V |
SL024924 | 120 | 165 | 45 | 222 | 440 | 2260 | 2.85 | NNCL4924V |
SL024926 | 130 | 180 | 50 | 260 | 510 | 2100 | 3.8 | NNCL4926V |
SL024928 | 140 | 190 | 50 | 270 | 550 | 1960 | 4.1 | NNCL4928V |
SL024930 | 150 | 210 | 60 | 410 | 820 | 1810 | 6.45 | NNCL4930V |
SL024932 | 160 | 220 | 60 | 425 | 880 | 1690 | 6.8 | NNCL4932V |
SL024934 | 170 | 230 | 60 | 435 | 930 | 1610 | 7.1 | NNCL4934V |
SL024936 | 180 | 250 | 69 | 570 | 1200 | 1510 | 10.5 | NNCL4936V |
SL024938 | 190 | 260 | 69 | 580 | 1270 | 1440 | 10.9 | NNCL4938V |
SL024940 | 200 | 280 | 80 | 680 | 1440 | 1340 | 15.3 | NNCL4940V |
SL024944 | 220 | 300 | 80 | 700 | 1550 | 1250 | 16.7 | NNCL4944V |
SL024948 | 240 | 320 | 80 | 740 | 1700 | 1150 | 17.9 | NNCL4948V |
SL024952 | 260 | 360 | 100 | 1100 | 2470 | 1050 | 31.2 | NNCL4952V |
SL024956 | 280 | 380 | 100 | 1150 | 2650 | 980 | 33.1 | NNCL4956V |
SL024960 | 300 | 420 | 118 | 1630 | 3700 | 910 | 51.9 | NNCL4960V |
SL024964 | 320 | 440 | 118 | 1700 | 4050 | 840 | 54.9 | NNCL4964V |
SL024968 | 340 | 460 | 118 | 1750 | 4250 | 810 | 57.8 | NNCL4968V |
SL024972 | 360 | 480 | 118 | 2020 | 4450 | 770 | 60.8 | NNCL4972V |
SL024976 | 380 | 520 | 140 | 2250 | 5500 | 720 | 90.5 | NNCL4976V |
SL024980 | 400 | 540 | 140 | 2310 | 5800 | 690 | 94.6 | NNCL4980V |
